Imagine ilustrativă
KUL6845LD2_EN
| Cod Ean | 8595568930644 |
| Cod vamal | 39259080 |
| Greutate | 0,05 kg/pcs |
| Material | PVC |
| Material fără plumb | yes |
| Izolare fonică | yes |
| Cu suto-stingere | 30 s |
| Voltaj nominal | <= 400 V |
| Curent nominal | <= 16 A |
| Rezistența la temperatură | -5 - 60 °C |
| Testat cu buclă incinsă | 850 °C |
| În medie | 73 mm |
| Adâncime | 45 mm |
| Diametrul orificiului găurit (forat) | 73 mm |
| Recomandările producătorului For all range of products in hollow walls, we recommend using the milling sets supplied by us. | |
| Clasa de reacție la foc | A1 - F |
| Tipuri de protecție | IP 30 |
| Standarde | ČSN EN 60 670-1 |
| Descriere impachetare boxes fitted with screws for mounting the box in plasterboard, the lid screwed to the box | |
Inlet openings made of flexible material. The instalation of the cable is done by pulling the pre-pressed inlet on the flexible membranes and inserting the cable or pipe into the hole formed. Air proofed even with inserted cable or pipe. Suitable for low energy and passive houses. Mounting screws are fitted with a double thread for quick installation, the box includes plastic feet. Prevents airflow through the installation. The IP30 protection complys a box fitted with a lid. When mounting, it is not necessary to countersink the plasterboard edge.
