Cod Ean8595057688339
Cod vamal39172290
Greutate0,1200 kg/m
Culoareblack
MaterialPC-ABS
Material fără halogeniyes
Stabil la UV/Material stabil la UVyes
Cu suto-stingere30 s
Rezistența la temperatură-45 - 90 °C
Rezistență mecanică1250 N/5cm
Protectie mecanicăIK09
Lungime3 m
Diametru exterior20 mm
Diametru interior (min.)15,7 mm
Toleranțălength ± 10 mm
Recomandările producătorului
The producer recommends the installation of plastic pipes at temperatures above 0 ° C.
Funcționalitate în focP90-R, E90, PS90
Zonă cu pericol de explozie
Can be installed in a zone with the danger of explosion of flammable gases and vapors of zone 2 and into the zone of danger of explosion of flammable dusts of zone 22.
Clasa de reacţie la foc a materialului de fondA1 - F
Cod se sortareKód triedenia44521
Standardele cu privire lade rezistența la focČSN 73 0895, DIN 4102-12, STN 92 0205
Încărcătură maximă pentru rezistența la foc10 kg

Halogen-free rigid socket pipes suitable for distribution systems in apartments and industrial environments. Up to a diameter of 25, the tubes have a socket at one end. Diameters 32 - 63 are fitted with a coupling. Halogen-free pipes are used on premises where the safety of people and property is primary, e.g.: public buildings, hospitals, schools, theatres, airport halls, shopping centres, etc.

Note for system with maintained functionality in fire:
max. 1 piece of cable in the pipe
You find more information in the catalogue Systems with maintained functionality in fire.
